The ES9000 electric strike is a high security product manufactured from solid stainless steel and designed to be used with most access control systems.
4 hour fire rating. And Australian Government listed.
The ES9000 is designed, developed and manufactured in Melbourne.
ID: 4903
Includes lip holes. Operates under pre-load up to 25kg. 4hrs fire rating when used with an approved door set. Suitable for use on hinged doors with fire or security requirements. Field selectable fail safe / fail secure. Equipped with a silencer pad on the keeper which significantly reduces noise when the strike is operated. Fully monitored - strike locked and door closed status. Solenoid monitor - 1 amp NO/NC microswitch. Door/latch monitor - 1 amp NO/NC microswitch. Stainless steel striker. Suitable for 15 mm latch and 3 mm door gap. 3 hardened locking pins. Solenoid can be continuously powered. Self adhesive installation template. Multi Voltage 12Vdc - 24Vdc. 250mA @12Vdc - 130mA @24Vdc. 1300kg static strength rating. 1,200,000 cycles endurance rating @ 25kg pre-load. Australian designed and made Approvals / Certifications C-Tick & CE compliant. Solenoid rated for continuous use. Built in protection diode. Mounting tabs as supplied standard. Weather resistant (IP54).
